2.5GBASE-LR+ SFP 1310nm 15km Duplex LC SMF

2.5GBASE-LR+ SFP 1310nm 15km Duplex LC SMF

P# FiberTK

Form Factor	SFP
Data Rate	2.5G
Max Distance	15km
Wavelength	1310nm
Connector	DuplexLC
Media Type	SMF
Transmitter Type	DFB
Receiver Type	PIN
TX Power	-8~-3dBm
Receiver Sensitivity	< -22dBm
Power Budget	14dB
Receiver Overload	-3dBm
Max Power Consumption	≤1.2W
Extinction Ratio	>9dB
DDM/DOM	支持
Operating Temperature	0～70℃（32～158°F）
Protocols	SFP MSA, SFF-8472, IEEE 802.3
Modulation	NRZ
BER	1E-12
MTBF	约10,000,000小时@40℃
Warranty	5年
Compatible With	Cisco
